OBN直型直柄開口扳手
| 圖片 | 型號 | 套筒齒輪對邊尺寸 | 扭矩范围（Nm） | 空转速度（rpm） | 全長 | 重量 | 進氣口尺寸 | 推薦氣管的內徑 | 耗氣量 | 噪音值 | ||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | 0.5-0.6MPa | 0.5-0.6MPa | mm | kg | in | mm | m3/min | dB | |||
 |
OBN-50SW-1 | 8.9.10 | 3/8.7/16 | 12-18 | 400-430 | 350 | 1.9 | PT 1/4 | 6.5 | 0.4 | 75 | |
 |
OBN-50SW-2 | 12.13.14.15.16.17 | 9/16 | 12-18 | 300-350 | 364 | 1.98 | PT 1/4 | 6.5 | 0.4 | 75 | |
 |
OBN-50SW-60-1 | 16.17.18 | 9/16 | 16-24 | 350-400 | 376 | 2.36 | PT 1/4 | 6.5 | 0.4 | 75 | |
 |
OBN-50SW-60-N | 16.17.18 | 9/16 | 16-24 | 350-400 | 376 | 2.36 | PT 1/4 | 6.5 | 0.4 | 75 | |
 |
OBN-50SW-70-1 | 19.20.21.22.23.24 | 3/4"、7/8" | 20-28 | 270-300 | 394 | 2.49 | PT 1/4 | 6.5 | 0.4 | 75 | |
 |
OBN-50SW-70-2 | 25.26.27.28.29.30 | 1(1/8)" | 25-40 | 220-250 | 416 | 2.79 | PT 1/4 | 6.5 | 0.4 | 75 | |
 |
OBN-60SW-1 | 16.17.18 | 9/16 | 40-55 | 430-480 | 383 | 2.37 | PT 1/4 | 6.5 | 0.43 | 76 | |
 |
OBN-60SW-N | 16.17.18 | 9/16 | 40-55 | 430-480 | 383 | 2.37 | PT 1/4 | 6.5 | 0.43 | 76 | |
 |
OBN-60SW-70-1 | 19.20.21.22.23.24 | 3/4"、7/8" | 45-60 | 33.-360 | 402 | 2.53 | PT 1/4 | 6.5 | 0.45 | 76 | |
 |
OBN-60SW-70-2 | 25.26.27.28.29.30 | 1(1/8)" | 55-75 | 270-290 | 423 | 2.83 | PT 1/4 | 6.5 | 0.45 | 76 | |
 |
OBN-70SW-1 | 19.20.21.22.23.24 | 3/4"、7/8" | 60(50)-(72)78 | 370-400 | 416 | 2.8 | PT 1/4 | 6.5 | 0.45 | 76 | |
 |
OBN-70SW-2 | 25.26.27.28.29.30 | 1(1/8)" | 105(82)-(65)82 | 290-320 | 437 | 3.1 | PT 1/4 | 6.5 | 0.45 | 76 | |
 |
OBN-70SW-60-1 | 16.17.18 | 9/16 | 45-60 | 470-530 | 397 | 2.64 | PT 1/4 | 6.5 | 0.45 | 76 | |
 |
OBN-70SW-60-N | 16.17.18 | 9/16 | 45-60 | 470-530 | 397 | 2.64 | PT 1/4 | 6.5 | 0.45 | 76 | |
 |
OBN-60SW-50-1 | 8.9.10 | 3/8.7/16 | 18-25 | 470-520 | 350 | 1.94 | PT 1/4 | 6.5 | 0.43 | 76 | |
 |
OBN-60SW-50-2 | 12.13.14.15.16.17 | 9/16 | 32-42 | 380-400 | 372 | 2.0 | PT 1/4 | 6.5 | 0.43 | 76 | |
