OBN枪型失速式工具

图片 型号螺栓直径 扭矩范围(Nm) 套筒或起子 空转速度(rpm) 全长 重量 进气口尺寸 推荐气管的内径 耗气量 噪音值
mm 0.5-0.6MPa in 0.4MPa 0.5MPa 0.6MPa mm kg in mm m3/min dB
OBN-30PD OBN-30PD 5-6 6-12 3/8 - - 4000 131 0.7 PT 1/4 6.5 0.2 75
OBN-40PD OBN-40PD 6 13-22 3/8 - - 4000 131 0.7 PT 1/4 6.5 0.2 75
OBN-50PD OBN-50PD 6-8 20-35 3/8 - - 7000 134 0.77 PT 1/4 6.5 0.25 78
OBN-60PD OBN-60PD 8-10 35-50 3/8 - - 6500 141 0.82 PT 1/4 6.5 0.4 80
OBN-70PD OBN-70PD 10 40-60 3/8 - - 6000 155 0.95 PT 1/4 8.0 0.45 80
OBN-80PD OBN-80PD 10 40-70 3/8 - - 5600 161.5 1.15 PT 1/4 8.0 0.48 80
OBN-81PD OBN-81PD 10-12 50-80 1/2 - - 5600 166.5 1.17 PT 1/4 8.0 0.48 80
OBN-90PD OBN-90PD 12 80-100 1/2 - - 5200 165 1.3 PT 1/4 8.0 0.53 82
OBN-100PD OBN-100PD 12-14 90-125 1/2 - - 4600 172 1.66 PT 1/4 8.0 0.58 80
OBN-130PD OBN-130PD 14 100-155 1/2 - - 4000 185 2.3 PT 1/4 12.7 0.65 82
OBN-150PD OBN-150PD 14-16 150-230 3/4 - - 3400 213.5 2.5 PT 1/4 12.7 0.7 82
OBN-180PD OBN-180PD 16-18 220-300 3/4 3200 226.5 3.0 PT 3/8 12.7 0.7 82
OBN-30PH OBN-30PH 5-6 6-12 1/4 - - 3800 131 0.7 PT 1/4 6.5 0.2 75
OBN-40PH OBN-40PH 6 10-20 1/4 - - 3800 131 0.7 PT 1/4 6.5 0.2 75
OBN-50PH OBN-50PH 6-8 18-30 1/4 - - 6200 134 0.77 PT 1/4 6.5 0.25 78
OBN-60PH OBN-60PH 8 25-35 1/4 - - 6500 142 0.82 PT 1/4 8.0 0.4 80
OBN-70PH OBN-70PH 8-10 35-45 1/4 - - 6700 155 0.95 PT 1/4 8.0 0.45 80
OBN-80PH OBN-80PH 8-10 45-60 1/4 6500 6800 170 1.18 PT 1/4 8.0 0.48 80
